Eagle Eye Networks DT01 4MP Turret Camera – 2.8mm IR
Eagle Eye Networks DT01 4MP Turret Camera – 2.8mm IR
Couldn't load pickup availability
Fixed-lens 4MP turret for general commercial coverage
The Eagle Eye Networks DT01 is an indoor/outdoor 4MP IP turret camera with a fixed 2.8 mm lens, Smart IR, built-in microphone, PoE and IP66 environmental protection. Its wide field of view suits entrances, parking areas, garages, warehouses, work yards and other general overview applications.
Why choose the DT01
- Best value for wide, fixed-view coverage
- Low-profile turret design without an exposed transparent dome
- Preconfigured for secure deployment with supported Eagle Eye video platforms
- NDAA-compliant model for commercial projects with sourcing requirements
Key specifications
| Model / Part number | DT01 / EN-CDUT-001a |
|---|---|
| Resolution | 4MP, up to 2592 × 1520 at 25/30 fps |
| Lens | Fixed 2.8 mm |
| Night vision | Smart IR, up to 40 m |
| Dynamic range | DWDR with HLC/BLC |
| Audio | Built-in microphone |
| Edge storage | microSD slot, up to 256GB |
| Power | IEEE 802.3af PoE or 12VDC; 7.5W maximum |
| Environmental | IP66; -40°F to 131°F |
Eagle Eye Cloud VMS service
An active Eagle Eye Networks service subscription is required for Eagle Eye Cloud VMS or Camera Direct operation. Hardware pricing does not include subscription charges unless specifically stated.
Avenger Security can provide the subscription, system sizing, installation, camera migration, retention planning and ongoing support. These are cloud-managed IP cameras; a project requiring a traditional closed-circuit system without internet or cloud services should use a conventional local VMS or NVR design instead.
Installation notes
- Use properly rated cabling and weatherproof cable terminations for outdoor installations.
- Select an approved junction box or mounting accessory where needed to protect connections and maintain the environmental seal.
- Confirm field of view, mounting height, network bandwidth, PoE capacity, retention and applicable audio-recording laws before installation.
For Eagle Eye camera design, migration, cloud retention and professional installation in Austin and Texas, see Avenger Security cloud video surveillance services.
